Place of Origin:
China
Brand Name:
Leader-t/OEM
Certification:
CE/ISO
Model Number:
LD-I-C-20
Contact Us
specification
| Configuration list | ||||
| Configuration | Material | SPEC | Brand | |
| Tank | FRP | 1665 | Domestic | |
| Value | / | Auto | Domestic | |
| Filter | quartz sand | 12-20 mesh | Domestic | |
| Active Carbon | 600-1100Mg/g | Domestic | ||
| Resin | / | Domestic PUROLITE,Rohm Hass | ||
| Ro membrance | Cellulose acetate membrane,element | DW30HRLE-440 | DOW | |
| Pipe/Value | ss304 | DN15-DN150 | Domestic | |
| Pump | SS/Iron/Copper | CNP,Grundfos | ||
| Optional | Customize the design according to the customer's URS | |||
| Application | Drinking, cleaning, beverage, industrial and mining enterprises and so on. |
|||
| productivity | 20L/h |
| Size | 48*31*60 |
| power | 50W |
| Standard supply voltage | 220V/50HZ/5A |
| Pre-treatment system | PP filter,soften filter,active carbon filter |
| Reverse osmosis stage | Single-stage |
| Production water | Ultrapure water |
1. The reverse osmosis device is an equipment to purify the saltine water with the action of pressure difference of semi permeable membrane. It is called reverse osmosis, as it is counter to natural penetration direction. Different materials have different osmotic pressures.
2. The reverse osmosis method to adopt larger osmotic pressures is used to obtain the purpose to separate, extract, purify and condense.
3. More than 97% soluble salts and 99%glues, microbe, particulate and organic substances and etc can be removed with the reverse osmosis.
4. It becomes the most idea equipment for the modem program of pure water, hyper pure water, and airspace water. The remarkable characteristics of the equipment are shown as lower energy consumption, no pollution, simple techniques, high water quality, easy operation and maintenance.
Process:
pictures:
